Perceptual SoundMax Audio Processors Model Q10-1111

portfolio

Perceptual SoundMax™ Model Q10-1111 is actually 3 products rolled into one. It provides 2 completely independent 10-band processing paths – one for on-air FM processing and one for Internet streaming. Additionally, a high quality AAC/AAC+/MP3 encoder for Internet streaming is built in which is capable of connecting with industry standard Icecast™ streaming servers, as well as other CDN networks. As part of our Internet Package this product also has an available web based player, requiring no additional apps or installations. This package also includes the use of our distributed, cloud based, CDN network. In terms of available audio processing modules the sophisticated 10-band processing engine is supplemented by a built-in broadcast grade wideband background noise removal product as well as a suite of audio conditioning/sweetening tools into one box, eliminating the need for broadcasters to place 3 or more separate hardware products in their broadcast chain to achieve the similar impact.

Features

  • 10 band dynamics processing.
  • Psychoacoustically Tuned.
  • Livelier, breathtakingly more detailed sound.
  • Novel Voice/Vocal enhancer makes the audio more natural.
  • Offers an attractive alpha-numeric TFT display for user control.
  • Additional signal processing tools to make audio more pleasing & less fatiguing to listen.
  • Uninterrupted 24x7 operations for years with minimum maintenance requirements.
  • Supplemented by sophisticated software that allow unsurpassed monitoring and tuning options using a networked PC based remote control.

Specifications

Analog Audio Input

Configuration

Left and Right (Dual mono)/Stereo


Connectors

Balanced XLR Female


Maximum Input Level/Impedence

+27dBu / >10kΩ


Nominal Input Level

Adjustable -10.0 to +13.0 dBu


EMI Suppressed

Yes

Analog Audio Output

Configuration

Stereo / Dual mono with independent level control


Output Level

Adjustable -6.0 to +24dBu, 600Ω or less


Crosstalk

≤ -90dB( 20Hz to 20KHz )


Distortion

THD≤0.01% ( 20Hz to 20KHz )


SNR

≥90dB ( 20Hz to 20KHz )


EMI Suppressed

Yes


Frequency Response

± 0.2 dB ( 5Hz to 20Khz )


Connectors

Balanced XLR,Male

Digital audio Input (AES/EBU)

Configuration

Stereo


Connectors

AES-XLR Female


Sampling Rate

32, 44.1, 48, 88.2 & 96 kHz (Auto Sense)


EMI Suppressed

Yes


Input Reference Level

-30.0 to 0 dBFs


Streaming Audio Output

Configuration

1 Internet Stream out.


Connectors

RJ-45, EMI Suppressed

Bit Rates

+32kbps - 256kbps


Player Compatibility

VLC,Windows Media,Real Player

Power

Power Requirements

105-260 V AC Single Phase, 50-60Hz


Connectors

IEC, EMI Suppressed, Detachable 3-wire chord


Safety Standards

UL, CE

Dimensions

Width

482.6mm


Height

44.5mm


Depth

508.0mm


Weight

6.5kg

Digital audio Output (AES/EBU)

Configuration

Stereo


Output Level

-20.0 to 0 dBFs


Connectors

AES-XLR Male


Sampling Rate

32, 44.1, 48, 88.2 & 96 kHz


EMI Suppressed

Yes


Frequency Response

± 0.2dB (5Hz to 20Khz)

Additional Features

AES/EBU Second Digital Output, RS-232 Serial Interface
